Sketch of 12 Lyncis (Struve 948)
Observation Notes:
12 Lyncis was a great triple star system. Color contrast was very nice–the primary appeared pale yellow, with a pale blue secondary hugging it. The tertiary appeared to be dull orange. They made for a very striking sight at 120X and 240X.
I measured the A-B pair at 63 degrees with a separation of 1.5 arc seconds (based on diffraction rings) to 2.2 arc seconds (based on the astrometric eyepiece gauge). I figured I had severely misread or mislabeled the PA measurement in my notes after looking up the WDS value: 156 degrees. However, that was an 1828 value. A little more checking showed that this is actually a fast moving pair. A 1998 measurement showed 72.7 degrees, and Brian Workman’s calculator comes up with 66.13 degrees for 2008.3. Currently the A-B pair is orbiting clockwise at about .5 degrees per year. Not as fast as Porrima’s periastron motion over the last few years, but still notable. My A-C measurement of 310 degrees and 8.6 arc-seconds matched up nicely with more stable values from WDS, Alzner 1998 & others.
| Subject | 12 Lyncis (STF 948) |
| Classification | Multiple Star |
| Position (J2000) | Lynx [RA: 6:46:14.3 / Dec: +59:26:30]* |
| Position Angle* |
A-B: 63° [2008.3 my measurement]; 66.13° [2008.3 Workman Calculator]; 72.7° [1998 Alzner]; 156° [1828 WDS] A-C: |
| Separation* |
A-B: 1.5″ – 2.2″ [2008.3 my measurement]; 1.7″ [2008.3 Workman Calculator]; 1.73″ [1998 Alzner]; 1.5″ [1828 WDS] A-C: |
| Magnitudes* | A: 5.3; B: 6.2; C: 7.2 |
| Spectral Types* | A: A2.5V; B: A2V; C: kA6hF1mF1 |
| Date/Time | APR 12, 2008 – 10:05 PM MST (APR 13, 2008 – 05:05 UT) |
| Observing Loc. | Flagstaff, Arizona, USA – Home |
| Instrument | Orion Skyview Pro 6LT (150 mm dia./1200 mm F/L) |
| Eyepieces/Mag. | 10 mm Sirius Plössl + 2X Barlow (240X) 12 mm Meade Astrometric EP + 2X Barlow (200X) |
| Conditions | Clear, first quarter moon |
| Seeing | 6/10 Pickering |
| Transparency | NELM Mag 5.0 |
| *References | The Washington Visual Double Star Catalog, Double stars measurements (Alzner 1998), Visual Double Stars in Hipparcos (Dommanget+, 2000), Catalogue of Stellar Spectral Classifications (Skiff, 2008) |
